Name: Electrolytic Tin Plate ETP Sheet with Corrosion Resistance DR-8 DR-9 and 0.15-0.5mm Thickness for Food Cans
Brand: SHANGHAI QUANYE METAL PACKAGING MATERIALS CO.,LTD
SKU: DR8 Placa de estaño
Price: 499.01 USD
Availability: InStock

Hogar > productos > Tin Plate electrolítico >

Electrolytic Tin Plate ETP Sheet with Corrosion Resistance DR-8 DR-9 and 0.15-0.5mm Thickness for Food Cans

Lugar de origen:

Porcelana

Nombre de la marca:

QuanJiang

Certificación:

MILL CERTIFICATE

Número de modelo:

DR8 Placa de estaño

Contáctenos

Solicitar presupuesto

Detalles del producto

Ancho:

600~1050m m

Dureza:

T-3 T-4 T-5 DR-7 DR-8 DR-9 DR-10 DEL T-2

Espesor:

0.15-0.5m m

Longitud:

600mm-1200mm o bobinas

Recubrimiento de estaño:

1,1/1,1, 2,0/2,0, 2,2/2,2, 2,8/2,8, 5,6/5,6, 8,4/8,4, 11,2/11,2 g/m2

Acabado superficial:

Brillante, piedra, de plata, mate

Pago y términos de envío

Cantidad de orden mínima

25 toneladas

Precio

Negotiated

Detalles de empaquetado

película plástica fina + plataformas a prueba de herrumbre de paper+carton+wooden

Tiempo de entrega

Negociado

Condiciones de pago

T/T

Capacidad de la fuente

50000 meses de la TA

PRODUCTOS RELACIONADOS

Vídeo

Corrosion Resistant Weldable 0.18mm Thick Tin Sheets and Tinplate for Food Cans

Consiga el mejor precio

Vídeo

Electrolytic Tin Plate ETP Sheet with Corrosion Resistance DR-8 DR-9 and 0.15-0.5mm Thickness for Food Cans

Consiga el mejor precio

Vídeo

Corrosion and Rust Resistant Tinplate Coils with Customizable Thickness for Food and Beverage Cans

Consiga el mejor precio

Vídeo

Food Grade Tinplate Sheet with Corrosion Resistant and Anti Rust Properties for Safe Food Storage

Consiga el mejor precio

Contáctenos

+8618267212962-021-56922400

quanye@spte.cn

+86-021-56922411

Contacto ahora

Descripción de producto

ETP Sheet Electrolytic Tin Plate for Aerosol Cans, Paint Cans, Food Cans

Product Overview

Tinplate is a thin steel sheet coated with tin, featuring an extremely beautiful metallic luster along with excellent corrosion resistance, solderability, and weldability. Tinplate is used for manufacturing various types of containers including food cans, beverage cans, 18-liter cans, and artistic cans. Beyond containers, tinplate is increasingly used for electrical machinery parts and numerous other industrial applications.

Key Features

Excellent Corrosion Resistance	By selecting proper coating weight, appropriate corrosion resistance is achieved against container contents.
Excellent Paintability & Printability	Printing is beautifully finished using various lacquers and inks for superior visual appeal.
Excellent Solderability & Weldability	Widely used for making various types of cans by soldering or welding processes.
Excellent Formability & Strength	By selecting proper temper grade, appropriate formability is obtained for various applications while maintaining required strength after forming.
Beautiful Appearance	Characterized by beautiful metallic luster with various surface roughness options by selecting substrate steel sheet surface finish.

Product Specifications

Parameter	Specification
Product	Tinplate Sheet, Tinplate Coil
Standard	ASTM A623, EN 10203, GB2520-2000, JISG3303-2002, DINEN10202-2001
Material	MR SPCC
Thickness	0.15-0.5mm (tolerance -/+0.01mm)
Width	700-1150mm (Tolerance: 0-3mm)
Cutting Length	700-1150mm (Tolerance: 0-3mm) or as coils
Annealing	BA & CA
Temper	T1 T2 T3 T4 T5 DR7 DR8 DR9 TH550 TH580 TH620 TH660
Tin Coating	1.1/1.1 2.0/2.0 2.8/2.8 2.8/5.6 5.6/5.6 8.4/8.4 11.2/11.2 g/㎡
Surface Finish	Bright, Stone, Silver, Matt
Coil Diameter	ID 420/508/610mm, OD from 1,000 to 1,250mm
Coil Weight	3-10 MT
Package	Seaworthy standard with wooden pallet, corner protected by sheet or coils according to customer requirements
Applications	Metal packaging for paint, chemical cans, aerosol cans, food cans; battery, electric cable, and other industries

Workshop Facilities

Company Profile

Shanghai Quanjiang Industrial Co., Ltd is a large-scale enterprise integrating manufacturing and international export. Established in 2001 with an area of more than 40,000 square meters located in Shanghai, China. We feature advanced production equipment including pushing machines, presses, large heat treatment furnaces, chamfering machines, sawing machines, large sandblasting machines, and various testing instruments.

Production Process

Application Examples

Quality Certifications

Frequently Asked Questions

Can you send samples?

Of course, we can send samples to all parts of the world. Our samples are free, but customers need to bear the courier costs.

What product information do I need to provide?

You need to provide the grade, width, thickness, coating, and the number of tons you need to purchase.

What are the shipping ports?

Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports. You can choose other ports according to your needs.

About product prices?

Prices vary from period to period due to cyclical changes in the price of raw materials.

What are the certifications for your products?

We have ISO 9001, SGS, EWC and other certifications.

How long does your delivery time take?

In general, our delivery time is within 30-45 days, and may be delayed if the demand is extremely large or special circumstances occur.

Can I visit your factory?

Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the public.

Does the product have quality inspection before loading?

Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

How are the products packaged?

The inner layer has waterproof paper, outer layer with iron packaging, and fixed with fumigation wooden pallets. This effectively protects products from corrosion during ocean transportation.
